Mercury Overview
First order capsules comparative arrangements

Pen and ink views of comparative arragements of several capsules including the existing "Big Joe" design, the compromise "Big Joe" design, and the "Little Joe". All capsule designs are labeled and include dimensions.



Catalog Date: 22 October 1963
Film Type: 4x5 BW
NASA image: S63-19317
