Apollo 17
Apollo 17 Command/Service modules photographed from lunar module in orbit

A view of the Apollo 17 command and service modules photographed from the lunar module (LM) Challenger during rendezvous and docking maneuvers in lunar orbit. The LM ascent stage, with astronauts Eugene A. Cernan and Harrison H. Schmitt aboard, had just returned from the Taurus-Littrow landing site on the lunar surface. Note the exposed Scientific Instrument Module (SIM) bay in sector 1 of the service module. Three experiments are carried in the bay: S-209 lunar sounder, S-171 infrared scanning spectrometer, and the S-169 far-ultraviolet spectrometer. Also mounted in the SIM bay are the panoramic camera, mapping camera and laser altimeter used in service module photographic tasks. A portion of the LM is on the right.

Catalog Date: 14 December 1972
Film Type: 70mm
NASA image: AS17-145-22254
